MF-P-HTD paper moisture sensor
Features:
- Measuring range: 1 to 20 % (depends on paper type)
- Paper basis weight range: 80 to 500 gsm
- Paper temperature range: 0 to +100°C / 32 to 212°F
- Environment temperature range: 0 to +70 °C / 32 to 158°F
- Power supply: 12 to 28 VDC or optional Power over Ethernet (PoE)
- Protection type: IP 65
- Scope of supply: MF-P-HTD sensor with mounted paper temperature sensor and paper control-roller set
- Analogue or digital output
The required interface must be ordered separately, further interfaces on request
Extended accessories
| Extended accessories | ||
|---|---|---|
| PC software for MF-P-HTD Software for moisture calculation, sort calibration, measurement display and measurement data management. Required for the moisture value calculation with the MF-P-HTD Sensor. Modbus interface required |
||
| Option Modbus TCP interface for MF-P-HTD | ||
| Option Analog output for MF-P-HTD | ||
| Laboratory analysis for creation of a calibration curve for PMSA or MF-P-HTD Creation of one calibration curve for a paper type . Paper sample must be provided by the customer. Five A4 sheets required per type. This article is only valid for one paper grammage. |
Auxiliary Modules
Accessories
